ПАРОБАРЬЕР С АРМИРУЮЩЕЙ СЕТКОЙ

VAPOR IN NET 140

Документы

ТЕХНИЧЕСКИЕ ХАРАКТЕРИСТИКИ
Декларация характеристик качества (DOP) Скачать
порядок монтажа
Environmental Product Declaration (EPD) Скачать

VAPOR IN NET 140

CODE description tape H
[m]
L
[m]
A
[m²]
H
[ft]
L
[ft]
A
[sft]
pcs./pallet
VV140 VAPOR IN NET 140 - 1.5 50 75 5 164 807 35

Technical Data
EN 13984
L C A L C A
EPD EPD EP D
national-classifications AT Önorm B3667 DB
national-classifications CH SIA 232 V.v.u.
national-classifications DE ZVDH Dh
national-classifications FR DTU 31.2 pare-vapeur
national-classifications IT UNI 11470 C/R2

Mass per unit area EN 1849-2 140 g/m² 0.46 oz/ft²
Thickness EN 1849-2 0,15 mm 6 mil
Water vapour transmission (Sd) EN 1931 25 m 0.14 PERM
Tensile strength MD/CD EN 12311-2 390 / 360 N/50mm 45 / 41 lb/in
Elongation MD/CD EN 12311-2 18 / 16 % -
Resistance to nail tearing MD/CD EN 12310-1 280 / 260 N 63 / 58 lbf
Watertightness EN 1928 compliant -
Thermal resistance - -20 / 80 °C -4 / 176 °F
Reaction to fire EN 13501-1 class E -
Resistance to penetration of air EN 12114 0 m³/(m²·h·50Pa) 0 cfm/ft² at 50Pa
Water vapour resistance - after artificial ageing EN 1296 / EN 1931 compliant -
Water vapour resistance - in the presence of alkalis EN 1847 / EN 12311-2 npd -
Thermal conductivity (λ) - 0,3 W/(m·K) 2.08 (BTU·in)/(h·ft²·°F)
Specific heat - 1800 J/(kg·K) -
Density - ca. 933 kg/m³ -
Water vapour resistance factor (μ) - ca. 167000 -
VOC content - 0 % -
Indirect exposure to UV rays - 2 weeks -

Composition

top layer vapour control PP film
REINFORCING LAYER reinforcing PP grid
bottom layer non-woven PP fabric
